Amaranth in practice: a case study with Maia SDR

Maia SDR is a new open-source FPGA-based SDR project focusing on the ADALM Pluto. The longer term goals of the project are to foster open-source development of SDR applications on FPGA and to promote the collaboration between the open-source SDR and FPGA communities. For the time being, focusing on developing a firmware image for the ADALM Pluto that uses the FPGA for most of the signal processing provides realistic goals and a product based on readily available hardware that people can already try and use during early stages of development.

The first version of Maia SDR was released on Februrary 2023, though its development started in September 2022. This version has a WebSDR-like web interface that displays a realtime waterfall with a sample rate of up to 61.44Msps and is able to make IQ recordings at that rate to the Pluto DDR (up to a maximum size of 400MiB per recording). These recordings can then be downloaded in SigMF format.

Exploring the RF world in the field with a portable device is one of the goals of Maia SDR, so its web UI is developed having in mind the usage from a smartphone and fully supports touch gestures to zoom and scroll the waterfall. A Pluto connected by USB Ethernet to a smartphone already give a quite capable and portable tool to discover and record signals.

The following figure shows a screenshot of the Maia SDR web user interface. More information about the project can be found in https://maia-sdr.net

Amaranth

Amaranth is an open-source HDL based in Python. The project is led by Catherine “whitequark”, who is one of the most active and prolific developers in the open-source FPGA community. Amaranth was previously called nMigen, as it was initially developed as an evolution of the Migen FHDL by M-Labs.

I cannot introduce Amaranth any better than Catherine, so I will just cite her words from the README and documentation.

The Amaranth project provides an open-source toolchain for developing hardware based on synchronous digital logic using the Python programming language, as well as evaluation board definitions, a System on Chip toolkit, and more. It aims to be easy to learn and use, reduce or eliminate common coding mistakes, and simplify the design of complex hardware with reusable components.

The Amaranth toolchain consists of the Amaranth hardware definition language, the standard library, the simulator, and the build system, covering all steps of a typical FPGA development workflow. At the same time, it does not restrict the designer’s choice of tools: existing industry-standard (System)Verilog or VHDL code can be integrated into an Amaranth-based design flow, or, conversely, Amaranth code can be integrated into an existing Verilog-based design flow.

The Amaranth documentation gives a tutorial for the language and includes as a first example the following counter with a fixed limit.

from amaranth import *

class UpCounter(Elaboratable):
    """
    A 16-bit up counter with a fixed limit.

    Parameters
    ----------
    limit : int
        The value at which the counter overflows.

    Attributes
    ----------

    en : Signal, in
        The counter is incremented if ``en`` is asserted, and retains
        its value otherwise.
    ovf : Signal, out
        ``ovf`` is asserted when the counter reaches its limit.
    """
    def __init__(self, limit):
        self.limit = limit

        # Ports
        self.en  = Signal()
        self.ovf = Signal()

        # State
        self.count = Signal(16)

    def elaborate(self, platform):
        m = Module()

        m.d.comb += self.ovf.eq(self.count == self.limit)

        with m.If(self.en):
            with m.If(self.ovf):
                m.d.sync += self.count.eq(0)
            with m.Else():
                m.d.sync += self.count.eq(self.count + 1)

        return m

Amaranth Elaboratable‘s are akin to Verilog module‘s (and in fact get synthesized to module‘s if we convert Amaranth to Verilog). IO ports for the module are created in the __init__() method. The elaborate() method can create additional logic elements besides those created in __init__() by instantiating more Signal‘s (this example does not do this). It also describes the logical relationships between all these Signals by means of a Module() instance usually called m. Essentially, at some point in time, the value of a Signal changes depending on the values of some Signal‘s and potentially on some conditions. Such point in time can be either continuously, which is described by the m.d.comb combinational domain, or at the next rising clock edge, which is described by the m.d.sync synchronous domain (which is, roughly speaking, the “default” or “main” clock domain of the module), or by another clock domain. Conditions are expressed using with statements, such as with m.If(self.en), in a way that feels quite similar to writing Python code.

For me, one of the fundamental concepts of Amaranth is the division between what gets run by Python at synthesis time, and what gets run by the hardware when our design eventually comes to life in an FPGA. In the elaborate() method we have a combination of “regular” Python code, which will get run in our machine when we convert the Amaranth design to Verilog or generate a bitstream directly from it, as well as code that describes what the hardware does. The latter is also Python code, but we should think that the effects of running it are only injecting that description into the list of things that Amaranth knows about our hardware design.

Code describing the hardware appears mainly in two cases: First, when we operate with the values of signals. For instance, self.count + 1 does not take the value of self.count and add one to it when the Python code is run. It merely describes that the hardware should somehow obtain the sum of the value of the register corresponding to self.count and the constant one. This expression is in effect describing a hardware adder, and it will cause an adder to appear in our FPGA design. This behaviour is reminiscent of how Dask and other packages based on lazy evaluation work (in Dask, operations with dataframes only describe computations; the actual work is only done eventually, when the compute() method is called). I want to stress that the expression self.count + 1 might as well appear in elaborate() only after a series of fairly complicated if and else statements using regular Python code. These statements will be evaluated at synthesis time, and our hardware design will end up having an adder or not depending on these conditions. Similarly, instead of the constant 1 in the + 1 operation, we could have a Python variable that is evaluated in synthesis time, perhaps as the result of running fairly complicated code. This will also affect what constant the hardware adder that we have in our design adds to the value of the self.count register.

Secondly, we have the control structures: m.If, m.Else, and a few more. These also describe hardware. Whether the condition is satisfied is not evaluated when the Python script runs. What these conditionals do is to modify the hardware description formed by the assignments to m.d.sync and m.d.comb that they enclose so that these assignments are only effective (or active) in the moments in which the condition is satisfied. In practice, these statements do two things in the resulting hardware: They multiplex between several intermediate results depending on some conditions, in a way that is usually more readable than using the Mux() operator that Amaranth also provides. They also control what logic function gets wired to the clock enable of flip-flops. Indeed, in some conditions a synchronous Signal() may have no active statements, in which case it should hold its current value. This behaviour can be implemented in hardware either by deasserting the clock enable of the flip-flops or by feeding back the output of the flip-flops to their input through a multiplexer. What is done depends mainly on choices done by the synthesis tool when mapping the RTL to FPGA elements. As before, we can have “regular” Python code that is run at synthesis time modifying how these m.If control structures look like, or even whether they appear in the design at all.

In a sense, the regular Python code that gets run at synthesis time is similar to Verilog and VHDL generate blocks. However, this is extremely more powerful, because we have all the expressiveness and power of Python at our disposal to influence how we build our design at synthesis time. Hopefully the following examples from Maia SDR can illustrate how useful this can be.

maia-hdl

maia-hdl is the FPGA design of Maia SDR. It is bundled as a Python package, with the intention to make easy to reuse the modules in third party designs. The top level of the design is an Amaranth Elaboratable that gets synthesized to Verilog and packaged as a Vivado IP core. As shown below, the IP core has re_in and im_in ports for the IQ data of the ADC, an AXI4-Lite subordinate interface to allow the ARM processor to control the core through memory-mapped registers, AXI3 manager interfaces for the DMAs of the spectrometer (waterfall) and IQ recorder, and ports for clocking and reset.

The IP core is instantiated in the block design of a Vivado project that gets created and implemented using a TCL script. This is based on the build system used by Analog Devices for the default Pluto FPGA bitstream. In this respect, Maia SDR gives a good example of how Amaranth can be integrated in a typical flow using the Xilinx tools.

There are two classes of unit tests in maia-hdl. The first are Amaranth simulations. These use the Amaranth simulator, which is a Python simulator than can only simulate Amaranth designs. These tests give a simple but efficient and powerful way of testing Amaranth-only modules. The second are cocotb simulations. Cocotb is an open-source cosimulation testbench environment for verifying VHDL and Verilog designs using Python. Briefly speaking, it drives an HDL simulator using Python to control the inputs and check the outputs of the device under test. Cocotb has rich environment that includes Python classes that implement AXI devices. In maia-hdl, cocotb is used together with Icarus Verilog for the simulation of designs that involve Verilog modules (which happens in the cases in which we are instantiating from Amaranth a Xilinx primitive that is simulated with the Unisim library), and for those simulations in which the cocotb library is specially useful (such as for example, when using the cocotb AXI4-Lite Manager class to test our AXI4-Lite registers).

One of the driving features of Maia SDR is to optimize the FPGA resource utilization. This is important, because the Pluto Zynq-7010 FPGA is not so large, specially compared with other Xilinx FPGAs. To this end, Amaranth gives a good control about how the FPGA design will look like in terms of LUTs, registers, etc. The example with the counter has perhaps already shown that Amaranth is a low-level language, in the same sense that Verilog and VHDL are, and nothing comparable to HLS (where regular C code is translated to an FPGA design).

FFT

The main protagonist of the Maia SDR FPGA design is a custom pipelined FFT core that focuses on low resource utilization. In the Maia SDR Pluto firmware it is used as a radix-2² single-delay-feedback decimation-in-frequency 4096-point FFT with a Blackman-harris window. It can run at up to 62.5 Msps and uses only around 2.2 kLUTs, 1.4 kregisters, 9.5 BRAMs, and 6 DSPs. One of the tricks that allows to save a lot of DSPs is to use a single DSP for each complex multiplication, by performing the three required real products sequentially with a 187.5 MHz clock. A description of the design of the FFT core is out of the scope of this article, but I want to show a few features that showcase the strengths of Amaranth.

The first is the FFTControl module. The job of this module is to generate the control signals for all the elements of the FFT pipeline. In each clock cycle, it selects which operation each butterfly should do, which twiddle factor should be used by each multiplier, as well as the read and write addresses to use for the delay lines that are implemented with BRAMs (these are used for the first stages of the pipeline, which require large delay lines). As one can imagine, these control outputs are greatly dependent on the synchronization of all the elements. For example, if we introduce an extra delay of one cycle in one of the elements, perhaps because we register the data to satisfy timing constraints, all the elements following this in the pipeline will need their control inputs to be offset in time by one cycle.

It is really difficult to implement something like this in Verilog or VHDL. Changing these aspects of the synchronization of the design usually requires rethinking and rewriting parts of the control logic. In Amaranth, our modules are Python classes. We can have them “talk to each other” at synthesis time and agree on how the control should be set up, in such a way that the result will still work if we change the synchronization parameters.

For example, all the classes that are FFT pipeline elements implement a delay Python @property that states what is the input to output delay of the module measured in clock cycles. For some simple modules this is always the same constant, but for a single-delay-feedback butterfly it depends on the length of the delay line of the butterfly, and for a twiddle factor multiplier it depends on whether the multiplier is implemented with one or three DSPs. These are choices that are done at synthesis time based on parameters that are passed to the __init__() method of these modules.

The FFTControl module can ask at synthesis time to all the elements that form the FFT pipeline what are their delays, and figure out the reset values of some counters and the lengths of some delay lines accordingly. This makes the control logic work correctly, regardless what these delays are. For instance, the following method of FFTControl computes the delay between the input of the FFT and the input of each butterfly by summing up the delays of all the preceding elements.

def delay_butterflies_input(self):
    """Gives the delay from the FFT input to the input of each of the
    butterflies"""
    return [
        self.delay_window
        + sum([butterfly.delay for butterfly in self.butterflies[:j]])
        + sum([twiddle.delay for twiddle in self.twiddles[:j]])
        for j in range(self.stages)
    ]

This is then used in the calculation of the length of some delay lines that supply the control signals to the butterflies. The code is slightly convoluted, but accounts for all possible cases. I don’t think it would be reasonable to do this kind of thing in Verilog or VHDL.

mux_bfly_delay = [
    [Signal(2 if isinstance(self.butterflies[j], R22SDF) else 1,
            name=f'mux_bfly{j}_delay{k}', reset_less=True)
     for k in range(0,
                    delay_butterflies_input[j]
                    - delay_twiddles_input[j-1]
                    + self.twiddles[j-1].twiddle_index_advance)]
     for j in range(1, self.stages)]

Another important aspect facilitated by Amaranth is the construction of a model. We need a bit-exact model of our FFT core in order to be able to test it in different situations and to validate simulations of the Amaranth design against the model. Each of the modules that form the pipeline has a model() method that uses NumPy to calculate the output of that module given some inputs expressed as NumPy arrays. Here is the model for a radix-2 decimation-in-frequency single-delay-feedback butterfly. Perhaps it looks somewhat reasonable if we remember that such a butterfly basically computes first x[n] + x[n+v//2], for n = 0, 1, ..., v//2-1, and then x[n] - x[n+v//2] for n = 0, 1, ..., v//2-1.

[class R2SDF(Elaboratable):]
[...]
def model(self, re_in, im_in):
    v = self.model_vlen
    re_in, im_in = (np.array(x, 'int').reshape(-1, 2, v // 2)
                    for x in [re_in, im_in])
    re_out, im_out = [
        clamp_nbits(
            np.concatenate(
                (x[:, 0] + x[:, 1], x[:, 0] - x[:, 1]),
                axis=-1).ravel() >> self.trunc,
            self.w_out)
        for x in [re_in, im_in]]
    return re_out, im_out

The interesting thing is that, since each of the FFT pipeline modules has its individual model, it is easy to verify the simulation of each module against its model separately. The model of the FFT module, which represents the whole FFT core, simply puts everything together by calling the model() methods of each of the elements in the pipeline in sequence. An important detail here is that the arrays self._butterflies and self._twiddles are the same ones that are used to instantiate and connect together the pipeline modules, in terms of the hardware design. By having these synergies between the model and the hardware design, we reduce the chances of them getting out of sync due to code changes.

[class FFT(Elaboratable):]
[...]
def model(self, re_in, im_in):
    v = self.model_vlen
    re = re_in
    im = im_in
    if self._window is not None:
        re, im = self._window.model(re, im)
    for j in range(self.nstages):
        re, im = self._butterflies[j].model(re, im)
        if j != self.nstages - 1:
            re, im = self._twiddles[j].model(re, im)
    return re, im

Instantiating Verilog modules and primitives

A question that often comes up is how to instantiate Verilog modules, VHDL entities or FPGA primitives in an Amaranth design. Kate Temkin has a short blog post about it. In maia-hdl this is used in in several cases, such as to implement clock domain crossing with the Xilinx FIFO18E1 primitive. The most interesting example is however the Cmult3x module, which implements complex multiplication with a single DSP48E1 that runs at three clock cycles per input sample (some simple algebra shows that a complex multiplication can be written with only three real multiplications).

When designing modules with DSPs, I prefer to write HDL code that will make Vivado infer the DSPs I want. This is possible in simple cases, but in more complicated situations it is not possible to make Vivado understand exactly what we want, so we need to instantiate the DSP48 primitives by hand.

The drawback of having an Amaranth design that contains instances of Verilog modules, VHDL entities or primitives is that we can no longer simulate our design with the Amaranth simulator. If our instances have a Verilog model (such as is the case with Xilinx primitives via the Unisim library), we can still convert the Amaranth design to Verilog and use a Verilog simulator. This is done in maia-hdl using Icarus Verilog and cocotb. However, this can be somewhat inconvenient.

There is another possibility, which is to write different implementations of the same Amaranth module. One of them can be pure Amaranth code, which we will use for simulation, and another can use Verilog modules or primitives. The two implementations need to be functionally equivalent, but we can check this through testing.

The way to acomplish this is through Amaranth’s concept of platform. The platform is a Python object that gets passed to the elaborate() methods of the modules in the design. The elaborate methods can then ask the platform for some objects that are usually dependent on the FPGA family, such as flip-flop synchronizers. This is a way of building designs that are more portable to different families. The platform objects are also instrumental in the process of building the bitstream completely within Amaranth, which is possible for some FPGA families that have an open-source toolchain.

In the case of the maia-hdl Cmult3x we simply check whether the platform we’ve been passed is an instance of XilinxPlatform and depending on this we have the elaborate() method either describe a pure Amaranth design that models the DSP48 functionality that we need, or instantiate a DSP48E1 primitive. Note that in the case of the pure Amaranth design we do not model the full functionality of the DSP48. Only that which is applicable to this use case.

[class Cmult3x(Elaboratable):]
[...]
def elaborate(self, platform):
    if isinstance(platform, XilinxPlatform):
        return self.elaborate_xilinx(platform)

    # Amaranth design. Vivado doesn't infer a single DSP48E1 as we want.
    [ ... here a pure amaranth design follows ... ]

def elaborate_xilinx(self, platform):
    # Design with an instantiated DSP48E1
    [...]
    m.submodules.dsp = dsp = Instance(
        'DSP48E1',
    [...]

Registers

Another aspect where the flexibility of Amaranth shines is in the creation of register banks. In maia-hdl, the module Register corresponds to a single 32-bit wide register and the module Registers forms a register bank by putting together several of these registers, each with their corresponding address. The registers support a simple bus for reads and writes, and an Axi4LiteRegisterBridge module is provided to translate between AXI4-Lite and this bus, allowing the ARM CPU to access the registers.

Registers and register banks are created with Python code that describes the fields of the registers. The basic ingredient is the Field named tuple:

Field = collections.namedtuple('RegisterField',
                               ['name', 'access', 'width', 'reset'])

We describe a register by giving it a name, an access mode (which can be read-only, write-only, read-write, or some other more specialized modes that we will describe below), a width, and a reset or default value.

The best way to understand how to work with these registers is to see how they are used in the Maia SDR top-level design.

self.control_registers = Registers(
    'control',
    {
        0b00: Register(
            'product_id', [
                Field('product_id', Access.R, 32, 0x6169616d)
            ]),
        0b01: Register('version', [
            Field('bugfix', Access.R, 8,
                  int(_version.split('.')[2])),
            Field('minor', Access.R, 8,
                  int(_version.split('.')[1])),
            Field('major', Access.R, 8,
                  int(_version.split('.')[0])),
            Field('platform', Access.R, 8, 0),
        ]),
        0b10: Register('control', [
            Field('sdr_reset', Access.RW, 1, 1),
        ]),
        0b11: Register('interrupts', [
            Field('spectrometer', Access.Rsticky, 1, 0),
            Field('recorder', Access.Rsticky, 1, 0),
        ], interrupt=True),
    },
    2)
self.recorder_registers = Registers(
    'recorder',
    {
        0b0: Register('recorder_control', [
            Field('start', Access.Wpulse, 1, 0),
            Field('stop', Access.Wpulse, 1, 0),
            Field('mode_8bit', Access.RW, 1, 0),
            Field('dropped_samples', Access.R, 1, 0),
        ]),
        0b1: Register('recorder_next_address', [
            Field('next_address', Access.R, 32, 0),
        ]),
    },
    1)

Here we show two register banks: one for the control of the IP core and another for the control of the IQ recorder. There is a similar third register bank for the control of the spectrometer (waterfall).

The parameters of the Registers constructor are a name, a dictionary that contains the registers in the bank (the keys of the dictionary are the addresses, and the values are the Register objects), and the width of the address bus. Note that these addresses correspond to the addressing of the native register bus. When we convert to AXI4-Lite, the addresses get shifted by two bits to the left because each register is 4 bytes wide.

The parameters of the Register constructor are a name and a list of Field‘s describing the fields of the register. Fields are allocated into the 32-bit register according to their order in the list, starting by the LSB. For instance, in the interrupts register, the spectrometer field occupies the LSB and the recorder field occupies the next bit.

If we look at the control registers, we can see that the registers for product_id and version have access type R, which means read-only. These registers are never wired in the design to other signals that would override their default values, so they are in fact constants that the CPU can read to check that the IP core is present and find its version number.

Next we have a control register, which has an sdr_reset field. This is wired internally to a bunch of reset signals in the IP core. It has a default value of 1, which means that most of the IP core starts in reset. The CPU can write a 0 to this field to take the IP core out of reset before using it. Accessing this sdr_reset field within the design is very simple, because the Registers and Register implement __getitem__(), allowing us to access them as if they were dictionaries. This example shows how it works. Here we are connecting the field sdr_reset to the reset input of something called rxiq_cdc (which implements clock domain crossing between the ADC sampling clock and the internal clock used in the IP core).

m.d.comb += rxiq_cdc.reset.eq(
    self.control_registers['control']['sdr_reset'])

If we look at the interrupts register, we can see an example of the Rsticky access mode. This means read-only sticky. A field of this type will be set to 1 when its input (which is wired internally in the IP core) has the value 1. It will keep the value 1 even if the input goes back to 0. The field is cleared and set to 0 when it is read. The intended use for this access mode is interrupts. A module can pulse the input of the field to notify an interrupt, and the field will hold a 1 until the CPU reads the register, clearing the interrupts. The interrupts register even has an interrupt=True option that provides an interrupt output that can be connected directly to the F2P interrupt port of the Zynq. This interrupt output will be high whenever any Rsticky field in the register is non-zero.

Finally, the recorder_control field gives some examples of the Wpulse access type. This is a write-only field with pulsed output. Writing a 1 to this field causes a one-cycle pulse at its output. This is ideal for controlling modules that require a pulse to indicate some event or command. For example, this is the case with the start and stop commands of the IQ recorder.

The Amaranth code that makes all of this work is not so complicated. You can take a look at the register.py file in maia-hdl to see for yourself.

Another interesting feature of this register system is that it can write an SVD file describing the register map. CMSIS-SVD is an XML format that is often used to describe the register maps of microcontrollers and SoCs. Maia SDR uses svd2rust to generate a nice Rust API for register access.

The Registers and Register classes have svd() methods that generate the SVD XML using Python’s xml.etree.ElementTree. This is relatively simple, because the classes already have all the information about these registers. It is, after all, the same information that they use to describe the hardware implementation of the registers. This is another example of how by using synergies between the code that describes the hardware design and code that does something related to that hardware design (in this case, writing SVD), we make it harder for changes in the code base to cause inconsistencies.

Conclusions

In this article we have gone from a “hello world” type counter in Amaranth to some rather intricate code from the inner workings of an FFT core. My intention with giving these code examples is not to expect the reader to understand all the code, but rather to give a feeling for how using Amaranth in complex projects can look like. Perhaps by now I have managed to convince you that Amaranth is a powerful and flexible alternative to HDLs such as Verilog and VHDL, or at least to get you interested in learning more about Amaranth and the world of open-source FPGA and silicon design.
